Artel FiberLink 4160

16 Channels of Independent Audio over one Fiber.

The Fiberlink 4160 Series digitally transmits sixteen independent audio channels over one multimode or single mode fiber at 850, 1310 or 1550 nm, with optional redundancy. It is ideal for Rental, Staging, Theater, Stadiums, Theme Parks and Broadcast applications.


  • Multiple Audio Channels – This product supports multiple channels of audio. Refer to the data sheet for more information.
  • Multimode Fiber – This product comes in a version that supports Multimode Fiber.
  • Single Mode Fiber – This product comes in a version that supports Single Mode Fiber.


  • Optional redundant optical input/output
  • System consists of transmitter and receiver unit
  • No adjustments; pure digital processing and transmission
  • 24 bit/96 kHz sampling; maximum audio level +24 dBu
  • 20 Hz to 20 kHz frequency response
  • Line level, balanced or unbalanced audio operation
  • Indicator LEDs monitor audio signals and power
  • Wide range internal power supply
  • Unit stands 1 RU high
  • Rack mount ears are included
